能量分辨率

Energy Resolution

< 5 meV

角度分辨率

Angular Resolution

< 0.1° for 0.1 mm emmission spot for He I

动量分辨率

k-Resolution

0.008 Å-1 for 0.1 mm emmission spot @ He I

接收角范围

Acceptance Angle

±90° full cone

μ-ARPES选区范围

μ-ARPES acceptance area

down to 2 μm

最小接收尺寸

Smallest Acceptance Spot

2 µm

空间分辨率 （PEEM模式）

Lateral Resolution

100 nm

探测器通道数

Detector Channels

1285 x 730 (with Channel Binning)

动能范围

Kinetic Energy Range

0-1500 eV

通过能

Pass Energies

1-200 eV Continously Adjustable

磁屏蔽

Magnetic Shielding

Double µ-Metal Shielding

能量分析方式

Energy Dispersion

Hemisphere

透镜模式

Lens Modes

PEEM Mode, Momentum Resolved Mode

测量模式

Measurement Modes

Snapshot Mode, Sweeping Mode

探测器通道数

Detector

2D CMOS Detector with Spin Option

狭缝/光缆

Slits/Apertures

8 entrance and 3 exit slits and iris aperture

能量窗口

Energy Window

13% of Pass Energy

电子学绝缘性

Electric Isolation

> 3.5 keV, 29 keV on lens system

电子学

Electronics

HSA + for KREIOS

工作压力

Working Pressure

10-11 to 10-7 mbar

工作距离

Working Distance

4-10 mm

安装法兰

Mounting Flange

DN150CF (8" OD)
