能量分辨率

Energy Resolution

< 15 meV

角度分辨率

Angular Resolution

< 0.1° for 0.1 mm emmission spot for He I

动量分辨率

k-Resolution

0.01 Å-1 for 0.1 mm emmission spot @ He I

接收角范围

Acceptance Angle

±90° full cone

μ-ARPES选区范围

μ-ARPES acceptance area

200μm down to 2 μm

最小接收尺寸

Smallest Acceptance Spot

2 µm

空间分辨率 （PEEM模式）

Lateral Resolution

50 nm

动能范围

Kinetic Energy Range

0-2000 eV

磁屏蔽

Magnetic Shielding

Double µ-Metal Shielding

能量分析方式

Energy Dispersion

Time of Fly

透镜模式

Lens Modes

PEEM Mode, Momentum Resolved Mode

探测器通道数

Detector

2D-DLD Detector with Spin Option

典型时间分辨率

Typical Time Resolution

< 180 ps
< 110 ps (best achieved)

重复频率

Start Repetition Rate

<150 MHz
<9 MHz without prescaller

硬件外触发

Hardware Triggering

Time reference start input,
Acquisition start,
Acquisition finished

电子学绝缘性

Electric Isolation

> 3.5 keV, 29 keV on lens system

电子学

Electronics

HSA + for KREIOS

工作压力

Working Pressure

10-11 to 10-7 mbar

工作距离

Working Distance

4-10 mm

安装法兰

Mounting Flange

DN150CF (8" OD)
